hibernate 所提供的一級快取(Session Level)，在同一個 session 下，如果對主鍵 select 兩次 相同的資料，其只會對 db 進行一次的 select，這個即為一級快取，很好了解。
Session level 快取會隨著 Session 生命週期起始與消滅。
來看良葛格的解釋 :
Session會維護一個Map容器，並保留與目前Session發生關係的資料，當您透過主鍵來載入資料時，Session會先依據所要載入的類別與所給定的主鍵，看看Map中是否已有資料，如果有的話就返回，若沒有就對資料庫進行查詢，並在載入資料後在Map中維護。
來看一下程式內容
public String firstCache() {
Users userA = usersService.getById(1L);
Users userB = usersService.getById(1L);
System.out.println("我們相同嗎 ? " + (userA == userB));
System.out.println("我是一級快取");
return SUCCESS;
}
result as below我們相同嗎 ? true 我是一級快取
結果顯示 : from 良格葛 -- 第二次查詢資料時，在快取中找到資料物件，於是直接返回，這與第一次查詢到的資料物件是同一個實例，所以會顯示 true 的結果。
那要怎麼將快取清掉呢?
可以透過evict()將某個物件從快取中移去，或使用clear()清除快取中的所有物件，
例如 :
public String firstCache() {
Users userA = usersService.getById(1L);
// session.clear() || session.evict(userA);
Users userB = usersService.getById(1L);
System.out.println("我們相同嗎 ? " + (userA == userB));
System.out.println("我是一級快取");
return SUCCESS;
}
則答案就會變成 false
我們相同嗎 ? false 我是一級快取
小結：當讀取的資料很大時，每一次 request 進來就去讀取一次，會造成相當的負擔，所以有了二級快取這個東西。
簡單講就是當資料沒有修改時，不管讀幾次，只要有設定二級快取，session 就算關閉了以後，二級快取裡如果有的話，也不會對 DB select。
以下開始介紹二級快取：
首先，先來看一下程式片段：
public String noCache() {
Users uA = usersService.getByAccount("markyeh");
System.out.println("我沒有 快取 : " + uA.getUpdateTime());
return SUCCESS;
}
然後我對點了這個連結兩次 http://localhost:8080/Cache/noCache.doresult as below：
Hibernate:
/*
FROM
Users
WHERE
account = ? */ select
users0_.id as id0_,
users0_.account as account0_,
users0_.address as address0_,
users0_.area1 as area4_0_,
users0_.area2 as area5_0_,
users0_.create_time as create6_0_,
users0_.email as email0_,
users0_.icon as icon0_,
users0_.mobile as mobile0_,
users0_.name as name0_,
users0_.password as password0_,
users0_.reg_ip as reg12_0_,
users0_.reg_random_code as reg13_0_,
users0_.roc_id as roc14_0_,
users0_.score as score0_,
users0_.state as state0_,
users0_.update_time as update17_0_
from
users users0_
where
users0_.account=?
我沒有 快取 : 2012-03-15 10:37:41.395
Hibernate:
/*
FROM
Users
WHERE
account = ? */ select
users0_.id as id0_,
users0_.account as account0_,
users0_.address as address0_,
users0_.area1 as area4_0_,
users0_.area2 as area5_0_,
users0_.create_time as create6_0_,
users0_.email as email0_,
users0_.icon as icon0_,
users0_.mobile as mobile0_,
users0_.name as name0_,
users0_.password as password0_,
users0_.reg_ip as reg12_0_,
users0_.reg_random_code as reg13_0_,
users0_.roc_id as roc14_0_,
users0_.score as score0_,
users0_.state as state0_,
users0_.update_time as update17_0_
from
users users0_
where
users0_.account=?
我沒有 快取 : 2012-03-15 10:37:41.395
執行結果：hibernate 對 db 進行了兩次的 select，但明明相同的東西，怎麼做才能只對 db select 一次就好呢？這裡就開始說明如何設定 hibernate 的二級快取：
我的環境如下
struts2 + hibernate + spring + ehcache(第三方實作 cache 的套件)
1. 在 spring 設定檔中，在 hibernate 注入的 bean 裡，增加二級快取的設定
<bean id="sessionFactory"
class="org.springframework.orm.hibernate3.annotation.AnnotationSessionFactoryBean">
<property name="dataSource" ref="ihergoSqlDataSource" />
<property name="hibernateProperties">
<props>
<!--
<prop key="hibernate.dialect">org.hibernate.dialect.MySQLInnoDBDialect</prop>
-->
<prop key="hibernate.dialect">org.hibernate.dialect.PostgreSQLDialect</prop>
<prop key="hibernate.connection.characterEncoding">utf-8</prop>
<prop key="hibernate.show_sql">true</prop>
<prop key="hibernate.format_sql">true</prop>
<prop key="hibernate.use_sql_comments">true</prop>
<prop key="hibernate.cache.use_second_level_cache">true</prop> <!-- 要不要使用二級快取 -->
<prop key="hibernate.cache.provider_class">org.hibernate.cache.EhCacheProvider</prop> <!-- 指定為 EHCache -->
<prop key="hibernate.cache.region.factory_class">net.sf.ehcache.hibernate.SingletonEhCacheRegionFactory</prop>
<prop key="hibernate.cache.use_query_cache">true</prop> <!-- query 也要快取-->
<prop key="hibernate.hbm2ddl.auto">update</prop>
</props>
</property>
<property name="packagesToScan">
<list>
<value>mt.buyer.db.entity</value>
</list>
</property>
</bean>
2. 設定 entity (以 annotation 為例)@Entity
@Cache(usage = CacheConcurrencyStrategy.READ_WRITE) // <---這裡, 只定為 read_write
@Table(name = "users")
public class Users implements Serializable {
@Id
@GeneratedValue(strategy = GenerationType.AUTO)
private long id;
/**
* 帳號
*/
@Column(name = "account", length = 20, nullable = false)
private String account;
...
}
3. 編寫 dao // 快取
public Users getByAccountUserCache(final String account) {
final String hql = "FROM Users WHERE account = :account ";
List memberList = getHibernateTemplate().executeFind(
new HibernateCallback>() {
public List doInHibernate(Session hbmSs)
throws HibernateException, SQLException {
// TODO Auto-generated method stub
Query query = hbmSs.createQuery(hql);
query.setString("account", account);
query.setCacheable(true); // <---- 這裡
return query.list();
}
});
if (memberList != null && memberList.size() > 0) {
return (Users) memberList.get(0);
}
return null;
}
// 沒有快取
public Users getByAccount(String account) {
final String hql = "FROM Users WHERE account = ?";
List memberList = getHibernateTemplate().find(hql, account);
if (memberList != null && memberList.size() > 0) {
return (Users) memberList.get(0);
}
return null;
}
4. 增加設定檔 ehcache.xml 並放在 src 下(預設讀取入徑, 也可用 spring 注入) <?xml version="1.0" encoding="UTF-8"?> <ehcache> <diskStore path="java.io.tmpdir" /> <defaultCache maxElementsInMemory="10000" eternal="false" overflowToDisk="true" timeToIdleSeconds="300" timeToLiveSeconds="180" diskPersistent="false" diskExpiryThreadIntervalSeconds="120" /> <!-- Hibernate --> <cache name="org.hibernate.cache.StandardQueryCache" maxElementsInMemory="5" eternal="false" timeToLiveSeconds="120" overflowToDisk="true"> </cache> <cache name="org.hibernate.cache.UpdateTimestampsCache" maxElementsInMemory="5000" eternal="true" overflowToDisk="true"> </cache> </ehcache>5. 測試程式 (action)
public String cache() {
Users uA = usersService.getByAccountUserCache("markyeh");
Users uB = usersService.getByAccountUserCache("markyeh");
System.out.println("快取 : " + uA.getUpdateTime());
System.out.println("快取 : " + uB.getUpdateTime());
return SUCCESS;
}
6. 執行連結 : http://localhost:8080/Cache/cache.do Hibernate:
/*
FROM
Users
WHERE
account = :account */ select
users0_.id as id0_,
users0_.account as account0_,
users0_.address as address0_,
users0_.area1 as area4_0_,
users0_.area2 as area5_0_,
users0_.create_time as create6_0_,
users0_.email as email0_,
users0_.icon as icon0_,
users0_.mobile as mobile0_,
users0_.name as name0_,
users0_.password as password0_,
users0_.reg_ip as reg12_0_,
users0_.reg_random_code as reg13_0_,
users0_.roc_id as roc14_0_,
users0_.score as score0_,
users0_.state as state0_,
users0_.update_time as update17_0_
from
users users0_
where
users0_.account=?
快取 : 2012-03-15 10:37:41.395
快取 : 2012-03-15 10:37:41.395
7. 可以發現, 第二次的查詢就已經沒有再進 db search 了, 如果再執行相同連結一次(也就是再發一個 request 到後台) 快取 : 2012-03-15 10:37:41.395 快取 : 2012-03-15 10:37:41.395可以看到，都是從二級快取的地方取得資料，這時，大家會問，那修改時怎麼判斷要不要取得新資料 8. 我們加入下面的程式碼：
public String update() {
// Users u = usersService.getByAccountUserCache("markyeh");
Users u = usersService.getByAccount("markyeh");
u.setArea1(3);
u.setUpdateTime(new Date());
usersService.update(u);
System.out.println("我修改了 : " + u.getUpdateTime());
return SUCCESS;
}
9. 分別依順序執行 3 個連結 a) http://localhost:8080/Cache/cache.do b) http://localhost:8080/Cache/update.do c) http://localhost:8080/Cache/cache.do // a) select
Hibernate:
/*
FROM
Users
WHERE
account = :account */ select
users0_.id as id0_,
users0_.account as account0_,
users0_.address as address0_,
users0_.area1 as area4_0_,
users0_.area2 as area5_0_,
users0_.create_time as create6_0_,
users0_.email as email0_,
users0_.icon as icon0_,
users0_.mobile as mobile0_,
users0_.name as name0_,
users0_.password as password0_,
users0_.reg_ip as reg12_0_,
users0_.reg_random_code as reg13_0_,
users0_.roc_id as roc14_0_,
users0_.score as score0_,
users0_.state as state0_,
users0_.update_time as update17_0_
from
users users0_
where
users0_.account=?
快取 : 2012-03-15 16:39:16.944
快取 : 2012-03-15 16:39:16.944
第一次執行, 結果一樣, 不會撈兩次
// b) update
Hibernate:
/*
FROM
Users
WHERE
account = ? */ select
users0_.id as id0_,
users0_.account as account0_,
users0_.address as address0_,
users0_.area1 as area4_0_,
users0_.area2 as area5_0_,
users0_.create_time as create6_0_,
users0_.email as email0_,
users0_.icon as icon0_,
users0_.mobile as mobile0_,
users0_.name as name0_,
users0_.password as password0_,
users0_.reg_ip as reg12_0_,
users0_.reg_random_code as reg13_0_,
users0_.roc_id as roc14_0_,
users0_.score as score0_,
users0_.state as state0_,
users0_.update_time as update17_0_
from
users users0_
where
users0_.account=?
Hibernate:
/* update
mt.buyer.db.entity.Users */ update
users
set
account=?,
address=?,
area1=?,
area2=?,
create_time=?,
email=?,
icon=?,
mobile=?,
name=?,
password=?,
reg_ip=?,
reg_random_code=?,
roc_id=?,
score=?,
state=?,
update_time=?
where
id=?
我修改了 : Thu Mar 15 16:40:19 CST 2012
// c) select
Hibernate:
/*
FROM
Users
WHERE
account = :account */ select
users0_.id as id0_,
users0_.account as account0_,
users0_.address as address0_,
users0_.area1 as area4_0_,
users0_.area2 as area5_0_,
users0_.create_time as create6_0_,
users0_.email as email0_,
users0_.icon as icon0_,
users0_.mobile as mobile0_,
users0_.name as name0_,
users0_.password as password0_,
users0_.reg_ip as reg12_0_,
users0_.reg_random_code as reg13_0_,
users0_.roc_id as roc14_0_,
users0_.score as score0_,
users0_.state as state0_,
users0_.update_time as update17_0_
from
users users0_
where
users0_.account=?
快取 : 2012-03-15 16:40:19.524
快取 : 2012-03-15 16:40:19.524
可以發現，ehcache 會自動判斷 cache 裡的東西跟 db 的記錄是不是不一樣了，如果不一樣會再 select 一次放入二級快取裡小結: ehcache.xml 可以設定的方式很多，這裡只是 demo，而我也還在學習，官方表示還可以做到 tx 的管理，所以還是去看一下文件比較好。
參考文件:
http://www.ehcache.org/documentation/user-guide/hibernate
http://renren.it/a/JAVAbiancheng/Spring/20101022/55282.html
http://caterpillar.onlyfun.net/Gossip/HibernateGossip/SecondLevelCache.html
進階，因公司架構 tomcat 為 cluster ，那...二級快取有辦法共用嗎? 答案是可以的
以下介紹 cluster 環境下怎麼共用二級快取的資料：
參考了官方文件後，必須加入第三方的套件 terracotta 先來看看官方的說明:
http://terracotta.org/documentation/enterprise-ehcache/get-started
其這套件就是一個 server ，經由這個 server 幫你控管各 session
而我測試的流程大概如下
1. 先裝 2 個tomcat，分別設定 port 為 8080, 8081
2. 加入相關 jar 檔
3. 修改 ehcache.xml
4. depoly 程式
5. 將 terracotta server run 起來
6. 測試
就從第二點開始：
2. ehcache 官網有寫，要做到For Terracotta clustering, download a full Ehcache distribution. 所以先下載好檔案，並解壓縮，內容會長這樣
<?xml version="1.0" encoding="UTF-8"?> <ehcache xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:noNamespaceSchemaLocation="ehcache.xsd" updateCheck="true" monitoring="autodetect"> <terracottaConfig url="localhost:9510" /> <!-- 連接到 terracotta server 的 ip 與 port --> <defaultCache maxElementsInMemory="10000" eternal="false" overflowToDisk="false" timeToIdleSeconds="300" timeToLiveSeconds="180" diskPersistent="false" diskExpiryThreadIntervalSeconds="120" /> <!-- diskPersistent 必須設成 false --> <!-- Hibernate --> <cache name="org.hibernate.cache.StandardQueryCache" maxElementsInMemory="5" eternal="false" timeToLiveSeconds="120" overflowToDisk="false"> <!-- overflowToDisk 必須設成 false --> <terracotta /> </cache> <cache name="org.hibernate.cache.UpdateTimestampsCache" maxElementsInMemory="5000" eternal="true" overflowToDisk="false"> <!-- overflowToDisk 必須設成 false --> <terracotta /> </cache> </ehcache>5. 在剛那個資料夾裡, 找到 \ehcache-2.5.1\terracotta\bin\start-tc-server.bat 並執行, 將 server run 起來
...
補充 :
分散式 cache 參考連結
http://www.informit.com/guides/content.aspx?g=java&seqNum=630
http://bbs.51osos.com/thread-4570-1-1.html
http://terracotta.org/documentation/enterprise-ehcache/configuration-guide
然後許多東西都沒有講, 如: terracotta 也可以加入 xml 設定檔, 設定 port, 而且 terracotta 本身也可以做 cluster
反正看一下官網就對了
以上
- A file ignored by version control. You can control what resources will be ignored by going to Window → Preferences → Team → Ignored Resources.
- A file not under version control. These are typically new files that you have not committed to the repository yet.
- A versioned file that needs to be added to the remote repository. These are typically files you have either renamed, or moved to a different directory.
- A deleted folder. These are folders that you have deleted locally without yet committing the changes to the repository. Note that files are usually removed from the view when they're deleted locally, so they are normally not seen with this icon.
- A file with no local changes.
- A file with local, uncommitted changes.
- A
- A file that needs a lock to be edited. These are typically files that cannot easily be merged (i.e. binary files), but may have many editors. A file needs a lock when its
-
-
- A file that is external to the project. Linked external files cannot be committed to the repository.
- A file that has been
- A file whose contents have been modified and will be committed to the repository.
- A file that will be newly added to the repository. This may coincide with a file removal in cases where a file is moved or renamed..
- A file that will be
-
- A file that has content changes committed to the repository that will be applied to the local copy.
- A new file that will be added to the local copy from the repository. Like the outgoing file addition, this may be the result of a move or rename.
- A file that will be removed from the local copy because it has been removed from the repository. Like the outgoing file removal, this may be the result of a move or rename.
-
-
) with the following buttons:
- Synchronizes the local copy with the currently selected repository when clicked. Selecting from the drop-down allows switching between different remote code bases.
- Shows only incoming changes (remote → local).
- Shows only outgoing changes (local → remote).
- Shows both incoming and outgoing changes (remote ↔ local).
- Shows conflicting changes.
- Updates all local resources with incoming changes after prompt.
- Brings up the commit dialog to commit all outgoing changes.
- Breaks up the change lists by revisions.
